6000 Ton - High Pressure Forged Frame
The high-strength and light-weight frame structure, delicately optimized for the 2025 Light Bee. The 6000-ton pressure forged frame makes rigidity and flexibility coexist to greatly improve handling and provide pure riding pleasure.
High Performance Mid-Motor
With a peak power of 8kW, it can bring the maximum torque of 266Nm at wheel and reach a top speed of 75km/h. The maximum motor speed exceeds 1500rpm to 5000rpm. The 38UH high-grade permanent magnet material can withstand high temperatures up to 180°C and is suitable for harsher conditions and riding environments.
FOC Smart Controller
The newly upgraded internal hardware structure is optimized for the high-performance motor of the Light Bee, making the three-phase current layout more uniform, greatly improving the current passing capacity and ensuring continuous and stable power output. The algorithm continuously improves based on the riders intention to adapt the bike to every individual rider.
The All-New 60V40Ah Lithium Battery Pack
The 50S cell is equipped with a safe and efficient battery management module, making its output powerful and stable. Multiple distributed temperature sensor and a SCM 485 protocol ensure the battery's high power load capacity and service life. The entire battery weighs only 11.6kg, can be quickly taken out in 10 seconds, and charge it easily anytime, anywhere.
New Discharge Plug
Upgraded specification to withstand higher power output. Features a single-connector design and easier battery installation and placement.
New Tuning of the Front and Rear Suspension Systems
-
The rebound damping, spring preload are adjustable in multiple stages. An adjustable air pressure assist function of 80-120psi is provided to improve load capacity, which can adjusted to find a more suitable riding style for you.
-
The Multi-link rear suspension system, with a 267mm fully adjustable cylinder rear shock absorber and 450lbs high-strength alloy spring. The appearance is integrated with t he bike shape and structure. The shock absorption is fine-tuned to always maintain the best grip.
Professional Off-Road Wheels
The newly upgraded front 70/100-19 and rear 3.00-18 wheel ensure strong grip. Compared to the previous generation the rear rim is changed to 18 inches resulting in a larger tier width and thicker wall, increasing comfort while further improving off-road performance.
Integrated Forged Opposite 4-Piston Braking System
The upgraded one-piece forged opposed 4-piston brake system has thickened the brake hose and greatly improved strength. The brake fluis has been increased to ensure that each piston can push the brake pads evenly and forcefully to provice stable and powerful braking power.
